Spesifikasi MotoGP


Type: Four-stroke
Configuration: Inline four-cylinder
Induction System: DOHC Pneumatic system, four valves per cylinder
Displacement: 798cc
Lubrication: Wet sump
Fuel System: Electronic Fuel Injection
Exhaust System: Titanium, four-into-two-into-one system
Maximum Power: in excess of 200 BHP
Maximum Speed: In excess of 300 km/h

Gearbox: Six speed, cassette type
Primary Drive: Gear
Clutch: Dry multi-plate slipper clutch
Final Drive: Chain
Lubrication: Wet sump

Frame: Aluminium twin-spar
Front Suspension: Inverted telescopic forks
Rear Suspension: Unit-trak Monoshock
Steering Damper: Hydraulic Adjustable
Bodywork: Carbon Fibre
Wheel Front: 16.5"
Wheel Rear: 16.5"
Tyres: Bridgestone

Front: 2 x 314mm carbon discs 2 x radial mount, monoblock, four piston calipers
Rear: 1 x 200mm ventilated steel disc 1 x two piston caliper

Wheelbase: 1460mm
Overall Length: 2080mm
Castor (Rake/Trail): Variable
Seat Height: 850mm
Dry Weight: Over 148kg
Fuel Capacity: 21 litres

Lubricants: Elf
Tyres: Bridgestone
Brakes: Brembo
Exhaust System: Akrapovic
Wheels: Magtan
Data Acquisition System: 2D Datarecording
Suspension: Öhlins
Clutch: FCC
Spark Plugs: NGK
Sprockets: AFAM
Chain: EK

Spesifikasi MotoGP : LCR HONDA (HONDA RC212V) MOTOGP
Engine features: Four stroke liquid cooled engine, V4, DOHC 4
Displacement: 800cc
Maximum Power: over 210 HP
Maximum Speed: over 325 km/H
Gearbox : Six speed cassette type gearbox with alternative optional ratio
Clutch : Fully adjustable multi plate slipper clutch
Exhaust : Titanium
Overall lenght : 2050mm to 2070mm up to circuit lay out and specification
Overall height : 1125mm
Overall width : 645mm
Weight : 148kg
Fuel : 21 litres capacity ELF
Oil : ELF
Chassis Features: Aluminium twin spare frameFully adjustable steering and geometryFully adjustable LCR magnesium tripple clamp
Suspensions : Front Fully adjustable Öhlins TTX20 upside downRear Fully adjustable Öhlins TTX36 Pro-link type link
Tyres : Michelin
Wheel : Marchesini
Brakes : Brembo front four piston caliper314mm carbon discRear twin piston caliperVentilated steel disc

Spesifikasi SUZUKI (GSV-R 2008) 2008

Type Mesin :4 stroke water cooled V4Kapasitas
Mesin :800ccMaksimum Power :225+ ps / 18,000rpmValve Control and
Type :Pneumatic (air control), DOHC four-valve
Karburasi :Fuel injectionLubrication
System :Wet sump (Motul Lubricants)
Clutch :Dry multi plates (back torque reduction type)
Transmisi :Six speed low friction constant meshFinal
Drive :ChainFrame
Type :Twin spar aluminum alloy frame
Suspensi :Front: Inverted type telescopic (Ohlins)
Rear: Link type (Ohlins)
Ban :Bridgestone
Wheels :Front and rear: 429mm (16.5 inches)
Brake System :Front: Double carbon disc (Brembo)
Rear: Single steel disc (Brembo)Overall
Length :2080mmOverall
Width :660mmOverall
Height :1150mm
Wheelbase :1450mm
Weight :148+kg
Fuel Tank :21LEstimated
Top Speed :330+km/h


Mesin :liquid-cooled, 90 degree V4 four-stroke, desmodromic DOHC, four valves per cylinder.
Kapasitas :799cc
Maksimum Power :more than 200hp
Maksimum Speed :in excess of 310 kph/192 mph
Transmisi :Six-speed cassette-type gearbox, with alternative gear ratios available. Dry multiplate slipper clutch. Chain final drive.
Karburasi :Indirect Magneti Marelli electronic injection, four throttle bodies with injectors above butterfly valves.Throttles operated by EVO TCF (Throttle Control & Feedback) system.
Fuel :Shell Racing V-
PowerOli :Shell Advance Ultra 4
Rangka :Tubular steel trellis-style chassis, pressed aluminium swing-arm.
Suspensi :Ohlins upside-down 42mm front forks and Ohlins rear shock absorber, adjustable for preload, compression and rebound damping.
Ban :Bridgestone 16.5" front and rear
Rem :Brembo, two 320mm carbon front discs with four-piston callipers. Single stainless steel rear disc with two-piston callipers.
Berat :148kg


Mesin :Liquid cooled inline four-cylinder, four stroke
Tenaga :Around 154.5 kw (210 horsepower)
Top Speed :In excess of 320 km/h
Transmisi :Six-speed cassette-type gearbox, with alternative gear ratios available
Chassis :Aluminium twin tube delta box, multi-adjustable steering geometry/wheelbase/ride height. Aluminium swingarm
Suspensi :Ohlins upside down front forks and Ohlins rear shock, all adjustable for pre-load, high and low-speed compression and rebound damping. Alternative rear suspension links available
Ban :- Michelin, 16.0 front, 16.5 in rear, available as slick,Intermediate and wet tyres on Jorge Lorenzo’s YZR-M1- Bridgestone, 16.5 front, 16.5 in rear, available as slick,Intermediate and wet tyres on Valentino Rossi’s YZR-M1
Rem :Brembo, two 320 mm carbon front discs, two four-piston callipers. Single 220 mm stainless steel rear disc, twin-piston calliper.
Berat :148 kg. In accordance with FIM regulations
